MG 400 Electrostatic Powder Coating Gun

The Micron manual powder coating gun is compatible with a large majority of domestic paint equipment. Its wide variety of nozzles allows for application on any material. Thanks to its 100kV high-voltage cascade, it ensures transfer efficiency and optimum continuity during application.

This product is for the paint spray gun only. The power cable, powder coating hose, and pneumatic vortex hose are not included.

MG 400 PISTOL TECHNICAL SPECIFICATIONS :

Nominal Input Voltage: 14V

Frequency: Approximately 18 kHz.

Nominal Output Voltage: 100 kV

Maximum Output Current: 100 µA

Polarity: Negative (positive-ops)

Paint Flow Rate: 50 - 600 gr. / minute

* The MG 400 pistol's rear cover is voltage controlled as shown in the picture, and the connection socket is a 6-pin socket.
